OJE-SS-105HM,000 - TE Connectivity

OJE-SS-105HM,000 Details

• Manufacturer Part Number:

  OJE-SS-105HM,000

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  TE Connectivity

• YTEOL:

  5.6

• Body Breadth:

  10.2 mm

• Body Height:

  14.7 mm

• Body Length or Diameter:

  18.2 mm

• Coil Current(DC)-Max:

  0.09 A

• Coil Operate Voltage(DC):

  3.5 V

• Coil Power:

  450 mW

• Coil Release Voltage(DC):

  0.25 V

• Coil Resistance:

  55.6 Ω

• Coil Voltage(DC)-Max:

  5 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  10A@250VAC

• Contact Current(AC)-Max:

  10 A

• Contact Current(DC)-Max:

  10 A

• Contact (DC) Max Rating R Load:

  10A@28VDC

• Contact Voltage(AC)-Max:

  277 V

• Contact Voltage(DC)-Max:

  30 V

• Contact/Output Supply Type:

  AC/DC

• Dielectric Strength Between Coil and Contacts:

  3000 Vrms

• Dielectric Strength Between Open Contacts:

  750 Vrms

• Electrical Life:

  100000 Cycle(s)

• End Contact Material:

  SILVER ALLOY

• Mounting Feature:

  PANEL MOUNT

• Operate Time:

  10 ms

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX; TRAY

• Physical Dimension:

  18.2mm x 10.2mm x 14.7mm

• Reference Standard:

  CSA; TUV; UL; VDE

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM A

• Relay Function:

  SPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  4 ms

• Surface Mount:

  NO

• Termination Type:

  SOLDER/QUICK CONNECT

• Weight:

  9 g
