OS203011MS1QP1 - LITTELFUSE

OS203011MS1QP1 Details

• Manufacturer Part Number:

  OS203011MS1QP1

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  Littelfuse Inc

• Actuator Color:

  BLACK

• Actuator Length:

  0.157 inch

• Actuator Material:

  POLYOXYMETHYLENE

• Actuator Type:

  SLIDE

• Body Breadth:

  6.8 mm

• Body Height:

  4.7 mm

• Body Length or Diameter:

  12.6 mm

• Center Contact Material:

  BRASS

• Center Contact Plating:

  SILVER

• Contact Current(DC)-Max:

  0.3 A

• Contact (DC) Max Rating R Load:

  .3A@30VDC

• Contact Function:

  ON-ON-ON

• Contact Resistance:

  0.02 mΩ

• Contact Voltage(DC)-Max:

  30 V

• Dielectric Withstand Volts:

  500VAC V

• Electrical Life:

  10000 Cycle(s)

• End Contact Material:

  COPPER ALLOY

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  PHENOLIC

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Positions:

  3

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -10 °C

• PCB Hole Count:

  10

• Packing Method:

  BULK

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  DP3T

• Switch Type:

  SLIDE SWITCH

• Terminal Finish:

  Silver (Ag)

• Terminal Material:

  BRASS

• Termination Type:

  SOLDER
