P82B715PN,112 - NXP

Description: NXP P82B715PN,112, 1-channel I/O Expander, I2C, SMBus, 8-Pin PDIP

Download P82B715PN,112 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
P82B715PN,112 - NXP PCB footprint - Dual-In-Line Packages - Dual-In-Line Packages - SOT97-1
click to zoom
3D Models
P82B715PN,112 - NXP  - 3D model - Dual-In-Line Packages - SOT97-1
click to zoom

P82B715PN,112 Details

  • Manufacturer Part Number:

    P82B715PN,112

  • Brand Name:

    NXP Semiconductor

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    DIP

  • Package Description:

    DIP-8

  • Pin Count:

    8

  • Manufacturer Package Code:

    SOT97-1

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    NXP Semiconductors

  • YTEOL:

    0

  • Interface IC Type:

    INTERFACE CIRCUIT

  • JESD-30 Code:

    R-PDIP-T8

  • Length:

    9.5 mm

  • Number of Functions:

    1

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    DIP

  • Package Equivalence Code:

    DIP8,.3

  • Package Shape:

    RECTANGULAR

  • Package Style:

    IN-LINE

  • Seated Height-Max:

    4.2 mm

  • Supply Voltage-Max:

    12 V

  • Supply Voltage-Min:

    4.5 V

  • Supply Voltage-Nom:

    5 V

  • Surface Mount:

    NO

  • Technology:

    BIPOLAR

  • Terminal Form:

    THROUGH-HOLE

  • Terminal Pitch:

    2.54 mm

  • Terminal Position:

    DUAL

  • Width:

    7.62 mm

P82B715PN,112 Frequently Asked Questions (FAQs)

  • The recommended operating voltage range for the P82B715PN,112 is 2.7V to 5.5V.
  • To ensure proper power-on and power-off, it's recommended to follow a power-up sequence: VCC, then VBAT, and power-down sequence: VBAT, then VCC.
  • The VBAT pin is used to connect a battery or a capacitor to store data during power-down. It should be connected to a battery or a capacitor with a value of at least 1uF.
  • The reset pin (RST) should be pulled high during power-up and power-down to ensure proper reset functionality.
  • The maximum clock frequency supported by the P82B715PN,112 is 20MHz.

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

P82B715PN,112 Overview

Use the download button to access the P82B715PN,112 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like P82B7, or try a keyword search, such as Other Interface ICs
