- Part Number PA6384-ALD
- Manufacturer COILCRAFT
- Pin Count 8
- Part Category Transformer
- Package Category Other
- Footprint Name Other - PA6384-ALD-5
- Released Date Jan 24, 2021
- Last Modified Date Mar 7, 2023 4:10 PM UTC
- Pinout / Pin List Click Here (Member Only)
PA6384-ALD Details
-
Manufacturer Part Number:
PA6384-ALD
-
Rohs Code:
Yes
-
Part Life Cycle Code:
Active
-
ECCN Code:
EAR99
-
Manufacturer:
Coilcraft Inc
-
YTEOL:
6.31
-
Additional Feature:
HEIGHT DIMENSION INCLUDES TERMINALS ALSO
-
Height:
11 mm
-
Input Voltage-Nom:
12 V
-
Length:
12.7 mm
-
Mounting Feature:
SURFACE MOUNT
PA6384-ALD Frequently Asked Questions (FAQs)
-
Coilcraft provides a recommended PCB land pattern in their application note AN-40, which can be found on their website. The land pattern is designed to ensure optimal performance and reliability of the inductor.
-
The PA6384-ALD is rated for operation up to 125°C. For high-temperature applications, it's essential to consider the derating curves provided in the datasheet to ensure the inductor operates within its specified parameters. Additionally, it's recommended to follow proper thermal management practices, such as providing adequate airflow and using thermal interfaces, to minimize temperature rise.
-
The PA6384-ALD is designed to meet the vibration requirements of various industries, including automotive and industrial. However, it's essential to follow proper mounting and soldering techniques to ensure the inductor is securely attached to the PCB. Additionally, it's recommended to perform vibration testing to ensure the inductor meets the specific requirements of your application.
-
To select the correct inductor value, you need to consider the specific requirements of your application, including the operating frequency, current, and voltage. Coilcraft provides an online inductor selection tool that can help you narrow down the options based on your specific requirements. Additionally, you can consult with a Coilcraft application engineer for guidance on selecting the optimal inductor value.
-
The lead time for PA6384-ALD can vary depending on the quantity, packaging, and shipping location. It's best to check with Coilcraft's website or contact their customer service department for the most up-to-date lead time information.
