PACDN046MR - onsemi

PACDN046MR Details

• Manufacturer Part Number:

  PACDN046MR

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  Micro 8 lead Surface Mount

• Package Description:

  MSOP-8

• Pin Count:

  8

• Manufacturer Package Code:

  846A-02

• Reach Compliance Code:

  Compliant

• Manufacturer:

  onsemi

• YTEOL:

  0

• Clamping Voltage-Max:

  8 V

• Configuration:

  COMMON ANODE, 6 ELEMENTS

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JESD-30 Code:

  S-PDSO-G8

• JESD-609 Code:

  e4

• Moisture Sensitivity Level:

  NOT SPECIFIED

• Number of Elements:

  6

• Number of Terminals:

  8

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity:

  UNIDIRECTIONAL

• Power Dissipation-Max:

  0.5 W

• Qualification Status:

  Not Qualified

• Rep Pk Reverse Voltage-Max:

  6.1 V

• Subcategory:

  Transient Suppressors

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  40
