PACSR48006S - Delta Electronics

PACSR48006S Details

• Manufacturer Part Number:

  PACSR48006S

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  PACKAGE-10

• ECCN Code:

  EAR99

• Manufacturer:

  Delta Electronics Inc

• YTEOL:

  0

• Analog IC - Other Type:

  AC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE, UL

• Control Mode:

  VOLTAGE-MODE

• Efficiency (Main Output):

  93.5%

• Input Voltage-Max:

  265 V

• Input Voltage-Min:

  85 V

• Input Voltage-Nom:

  110 V

• JESD-30 Code:

  R-MXFM-P10

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  10

• Output Current-Max:

  6.3 A

• Output Voltage-Max:

  48.5 V

• Output Voltage-Min:

  47.5 V

• Output Voltage-Nom:

  48 V

• Package Body Material:

  METAL

• Package Code:

  XFM

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  255

• Protections:

  OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE; THERMAL

• Ripple Voltage (Main Out):

  0.03535 Vrms

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  UNSPECIFIED

• Time@Peak Reflow Temperature-Max (s):

  6

• Total Power Output-Max:

  300 W

• Trim/Adjustable Output:

  NO

• Warm-up Time:

  1.5 s
