PAT0816-C-4DB-T5 Frequently Asked Questions (FAQs)

• What is the recommended land pattern for PAT0816-C-4DB-T5?
  The recommended land pattern for PAT0816-C-4DB-T5 is a rectangular pad with a size of 1.2mm x 0.8mm, with a solder mask clearance of 0.1mm. It's essential to follow the recommended land pattern to ensure reliable soldering and to prevent thermal stress.
• Can PAT0816-C-4DB-T5 be used in high-temperature applications?
  While PAT0816-C-4DB-T5 has a rated operating temperature range of -55°C to 125°C, it's not recommended for high-temperature applications above 105°C. Prolonged exposure to high temperatures can affect the resistor's stability and reliability. If high-temperature operation is required, consider using a different resistor model or consulting with Susumu Co Ltd's application engineers.
• How does PAT0816-C-4DB-T5 handle power surges and pulses?
  PAT0816-C-4DB-T5 is designed to handle power surges and pulses within its rated power dissipation. However, it's essential to ensure that the resistor is properly derated to handle the expected power surge or pulse conditions. Consult the datasheet and application notes for guidance on derating and surge handling.
• Is PAT0816-C-4DB-T5 compatible with lead-free soldering processes?
  Yes, PAT0816-C-4DB-T5 is compatible with lead-free soldering processes. Susumu Co Ltd's resistors are designed to meet the requirements of lead-free soldering, and they can withstand the higher temperatures associated with lead-free soldering processes.
• What is the typical tolerance for PAT0816-C-4DB-T5?
  The typical tolerance for PAT0816-C-4DB-T5 is ±1%. However, it's essential to check the specific tolerance for the particular batch or lot of resistors, as it may vary. Consult the datasheet or contact Susumu Co Ltd's sales or application engineers for more information.
