PBSS4112PANP,115 - Nexperia

Description: Bipolar Transistors - BJT 120V 1A NPN/PNP lo VCEsat transistor 120 V, 1 A NPN/PNP low VCEsat (BISS) transistor

Download PBSS4112PANP,115 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
PBSS4112PANP,115 - Nexperia - PCB symbol
click to zoom
PCB Footprints
PBSS4112PANP,115 - Nexperia PCB footprint - Other - Other - DFN2020-6 (SOT1118)_2023
click to zoom
3D Models
PBSS4112PANP,115 - Nexperia - 3D model - Other - DFN2020-6 (SOT1118)_2023
click to zoom

PBSS4112PANP,115 Details

  • Manufacturer Part Number:

    PBSS4112PANP,115

  • Brand Name:

    Nexperia

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    DFN

  • Package Description:

    SOT-1118, DFN2020-6, 6 PIN

  • Pin Count:

    6

  • Manufacturer Package Code:

    SOT1118

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    EAR99

  • Factory Lead Time:

    8 Weeks

  • Manufacturer:

    Nexperia

  • YTEOL:

    7

  • Case Connection:

    COLLECTOR

  • Collector Current-Max (IC):

    1 A

  • Collector-Base Capacitance-Max:

    7 pF

  • Collector-Emitter Voltage-Max:

    120 V

  • Configuration:

    SEPARATE, 2 ELEMENTS

  • DC Current Gain-Min (hFE):

    30

  • JESD-30 Code:

    S-PDSO-N6

  • Moisture Sensitivity Level:

    1

  • Number of Elements:

    2

  • Number of Terminals:

    6

  • Operating Temperature-Max:

    150 °C

  • Operating Temperature-Min:

    -55 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Shape:

    SQUARE

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    260

  • Polarity/Channel Type:

    NPN AND PNP

  • Power Dissipation-Max (Abs):

    1.45 W

  • Reference Standard:

    IEC-60134

  • Surface Mount:

    YES

  • Terminal Finish:

    Tin (Sn)

  • Terminal Form:

    NO LEAD

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    40

  • Transistor Application:

    SWITCHING

  • Transistor Element Material:

    SILICON

  • Transition Frequency-Nom (fT):

    120 MHz

  • VCEsat-Max:

    0.24 V
