Part Image

PBSS4240DPN - Nexperia

Description: PBSS4240DPN, Dual NPN + PNP Bipolar Transistor 1.1/1.35A 40V HFE:50V 150MHz, 6-Pin TSOP

Download ECAD Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download

PCB Footprints

PBSS4240DPN - Nexperia PCB footprint - SOT23 (6-Pin) - SOT23 (6-Pin) - SOT457 (SC-74)
click to zoom

3D Models

PBSS4240DPN - Nexperia  - 3D model - SOT23 (6-Pin) - SOT457 (SC-74)
click to zoom

PBSS4240DPN Details

  • Manufacturer Part Number:

    PBSS4240DPN

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Reach Compliance Code:

    compliant

  • Country Of Origin:

    Malaysia

  • ECCN Code:

    EAR99

  • Date Of Intro:

    2017-02-01

  • Manufacturer:

    Nexperia

  • Risk Rank:

    7.17

  • Samacsys Modified On:

    2021-10-25 07:51:10

  • YTEOL:

    7.5

  • Collector Current-Max (IC):

    1.35 A

  • Collector-Base Capacitance-Max:

    12 pF

  • Collector-Emitter Voltage-Max:

    40 V

  • Configuration:

    SEPARATE, 2 ELEMENTS

  • DC Current Gain-Min (hFE):

    200

  • JESD-30 Code:

    R-PDSO-G6

  • JESD-609 Code:

    e3

  • Moisture Sensitivity Level:

    1

  • Number of Elements:

    2

  • Number of Terminals:

    6

  • Operating Temperature-Max:

    150 °C

  • Operating Temperature-Min:

    -65 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    260

  • Polarity/Channel Type:

    NPN AND PNP

  • Power Dissipation-Max (Abs):

    0.6 W

  • Reference Standard:

    IEC-60134

  • Surface Mount:

    YES

  • Terminal Finish:

    Tin (Sn)

  • Terminal Form:

    GULL WING

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Transistor Application:

    SWITCHING

  • Transistor Element Material:

    SILICON

  • Transition Frequency-Nom (fT):

    150 MHz

  • VCEsat-Max:

    0.4 V

Risk Rank: Design Risk

PBSS4240DPN — Nexperia
2.2 - Low Design Risk
Design Risk Rank is determined by in-depth analysis across multiple factors, including part availability, functional equivalents, lifecycle and more. Learn more →

Risk Rank

Risk Rank is a proprietary algorithm Supplyframe has developed to quantify component risk using multiple data points. This ranking helps engineers and buyers determine whether alternates should be sought for parts that are deemed as high risk.

Risk Rank Example

Risk Rank is determined by a combination of factors such as product lifecycle status, price & inventory volatility, current inventory availability and much more. Even the availability of manufacturer specifications, part documentation such as datasheets and reference designs have an impact on determining the overall riskiness of a part.

The risk is characterized across three product phases:

  • Design
  • Production
  • Long Term

We focus on the Design Phase on Component Search Engine in our evaluation of Risk.

Design Phase

The design phase of a product is at the beginning of the product lifecycle. This is when engineers are doing analysis of components in the marketplace, determining which specifications are most important for their design and assessing the cost impact of using this particular component. While this is early in the product lifecycle, choices at this point can severely impact a product much later on when the product is being made. Additionally, this stage is the one furthest from a product being made, which is why we focus on metrics of stability over time when determining Design Risk.

Risk Rank Breakdown

Trust Checks

Community Provided
System Verified
Community Approved
Sponsored

PBSS4240DPN Overview

Use the download button to access the PBSS4240DPN schematic symbol, PCB footprint, and 3D model.
PBSS4240DPN by Nexperia has a score of
To find more CAD model downloads similar to this part, try a partial part number search, like PBSS4, or try a keyword search, such as Small Signal Bipolar Transistors
