PCF1171CT - NXP

PCF1171CT Details

• Manufacturer Part Number:

  PCF1171CT

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SOIC

• Package Description:

  PLASTIC, SOT-158-2, VSOP-40

• Pin Count:

  40

• HTS Code:

  8542.39.00.60

• Manufacturer:

  NXP Semiconductors

• YTEOL:

  0

• Additional Feature:

  COLON FLASH

• Alarm:

  NO

• Application:

  CAR CLOCK

• Battery End of Life Indication:

  NO

• Consumer IC Type:

  LCD CLOCK

• Display Mode:

  DIGITAL

• Frequency Trimming:

  NO

• JESD-30 Code:

  R-PDSO-G40

• JESD-609 Code:

  e0

• Length:

  15.4 mm

• Moisture Sensitivity Level:

  1

• Number of Functions:

  1

• Number of Terminals:

  40

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Frequency-Nom:

  4.194304 MHZ

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SSOP

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, SHRINK PITCH

• Peak Reflow Temperature (Cel):

  240

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  2.7 mm

• Supply Current-Max:

  0.7 mA

• Supply Voltage-Max (Vsup):

  6 V

• Supply Voltage-Min (Vsup):

  3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.762 mm

• Terminal Position:

  DUAL

• Width:

  7.55 mm
