PCF2131TF - NXP

PCF2131TF Details

• Manufacturer Part Number:

  PCF2131TF

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Thailand

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  NXP Semiconductors

• YTEOL:

  13

• Clock Frequency-Max:

  0.032 MHz

• Information Access Method:

  SERIAL(I2C/SPI)

• Interrupt Capability:

  Y

• JESD-30 Code:

  R-PDSO-N16

• Length:

  4.5 mm

• Moisture Sensitivity Level:

  3

• Number of Terminals:

  16

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HSON

• Package Equivalence Code:

  SOLCC16,.14,20

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG

• Seated Height-Max:

  1.5 mm

• Supply Current-Max:

  0.8 mA

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  1.8 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  DUAL

• Time-Min:

  1/100 SECOND

• Volatile:

  NO

• Width:

  3.5 mm

• uPs/uCs/Peripheral ICs Type:

  TIMER, REAL TIME CLOCK
