PCI9052 - PLX TECHNOLOGY

PCI9052 Details

• Manufacturer Part Number:

  PCI9052

• Pbfree Code:

  No

• Part Life Cycle Code:

  Transferred

• Part Package Code:

  QFP

• Package Description:

  PLASTIC, QFP-160

• Pin Count:

  160

• ECCN Code:

  3A991.a.2

• HTS Code:

  8542.31.00.30

• Manufacturer:

  PLX Technology

• Address Bus Width:

  32

• Bus Compatibility:

  ISA

• Clock Frequency-Max:

  33 MHz

• Data Transfer Rate-Max:

  132 MBps

• External Data Bus Width:

  32

• JESD-30 Code:

  S-PQFP-G160

• JESD-609 Code:

  e0

• Length:

  28 mm

• Number of Terminals:

  160

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  QFP

• Package Equivalence Code:

  QFP160,1.2SQ

• Package Shape:

  SQUARE

• Package Style:

  FLATPACK

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  4 mm

• Supply Current-Max:

  130 mA

• Supply Voltage-Max:

  5.25 V

• Supply Voltage-Min:

  4.75 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  QUAD

• Width:

  28 mm

• uPs/uCs/Peripheral ICs Type:

  BUS CONTROLLER, PCI
