PCS040-EF13340S - Bourns

PCS040-EF13340S Details

• Manufacturer Part Number:

  PCS040-EF13340S

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CHIP

• ECCN Code:

  EAR99

• Factory Lead Time:

  16 Weeks

• Manufacturer:

  Bourns Inc

• YTEOL:

  8

• Additional Feature:

  LENGTH & HEIGHT DIM INCLUDE TERMINAL ALSO

• ET Product-Min:

  50.8 V-us

• Height:

  10.5 mm

• Length:

  19.91 mm

• Load Resistance:

  0.18 Ω

• Mounting Feature:

  SURFACE MOUNT

• Operating Frequency-Max:

  1000 kHz

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  TR, 13 INCH

• Peak Primary Current:

  40 A

• Primary Type:

  WOUND PRIMARY

• Secondary Inductance:

  340 µH

• Surface Mount:

  YES

• Transformer Type:

  CURRENT SENSE TRANSFORMER

• Turns Ratio (Np:Ns):

  1:20

• Width:

  14.55 mm
