PCV-1-182-15L - COILCRAFT

PCV-1-182-15L Details

• Manufacturer Part Number:

  PCV-1-182-15L

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  RADIAL LEADED

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Manufacturer:

  Coilcraft Inc

• YTEOL:

  6

• Construction:

  Open Core

• Core Material:

  FERRITE

• DC Resistance:

  0.003 Ω

• Inductance-Nom (L):

  1.8 µH

• Inductor Application:

  POWER INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• JESD-609 Code:

  e2

• Lead Diameter:

  1.73 mm

• Lead Length:

  7.1 mm

• Lead Spacing:

  10.7 mm

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Diameter:

  16.5 mm

• Package Length:

  27.9 mm

• Package Style:

  Radial

• Packing Method:

  Tray

• Rated Current-Max:

  19.3 A

• Shape/Size Description:

  CYLINDRICAL PACKAGE

• Shielded:

  NO

• Surface Mount:

  NO

• Terminal Finish:

  Tin/Silver (Sn/Ag)

• Terminal Placement:

  RADIAL

• Terminal Shape:

  WIRE

• Test Frequency:

  0.01575 MHz

• Tolerance:

  15%
