PD69108ILQ-TR - Microchip

PD69108ILQ-TR Details

• Manufacturer Part Number:

  PD69108ILQ-TR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  HVQCCN, LCC48,.32SQ,20

• Pin Count:

  48

• Manufacturer Package Code:

  VQFN-48

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Philippines, Thailand

• HTS Code:

  8542.31.00.30

• Factory Lead Time:

  7 Weeks

• Manufacturer:

  Microchip Technology Inc

• YTEOL:

  0

• JESD-30 Code:

  S-PQCC-N48

• Length:

  8 mm

• Moisture Sensitivity Level:

  3

• Number of Terminals:

  48

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC48,.32SQ,20

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Peak Reflow Temperature (Cel):

  260

• Seated Height-Max:

  1 mm

• Supply Voltage-Max:

  57 V

• Supply Voltage-Min:

  44 V

• Supply Voltage-Nom:

  55 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Time@Peak Reflow Temperature-Max (s):

  40

• Width:

  8 mm

• uPs/uCs/Peripheral ICs Type:

  PSE CONTROLLER
