PDQ10-Q24-D12-D Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal performance?
  CUI recommends a 4-layer PCB with a solid ground plane and a separate layer for the input and output voltage rails to minimize noise and EMI. Additionally, keep the input and output capacitors close to the module to reduce parasitic inductance.
• How do I ensure reliable operation in high-temperature environments?
  CUI recommends derating the output power by 2.5% per degree Celsius above 40°C to ensure reliable operation. Additionally, ensure good airflow around the module and consider using a heat sink if necessary.
• What is the maximum allowable input voltage ripple?
  CUI recommends keeping the input voltage ripple below 10% of the nominal input voltage to ensure stable operation. Excessive input voltage ripple can affect the module's performance and reliability.
• Can I use this module in a redundant configuration?
  Yes, the PDQ10-Q24-D12-D can be used in a redundant configuration, but it requires careful consideration of the system design and implementation. CUI recommends consulting with their application engineers to ensure a reliable and efficient redundant system.
• What is the typical MTBF (Mean Time Between Failures) of this module?
  CUI estimates the MTBF of the PDQ10-Q24-D12-D to be around 1.5 million hours, based on MIL-HDBK-217F calculations. However, this value can vary depending on the specific application and operating conditions.
