PDQ30-Q48-D15-D Frequently Asked Questions (FAQs)

• What is the recommended PCB layout and thermal management for optimal performance?
  CUI recommends a PCB layout with a solid ground plane and thermal vias to dissipate heat. A minimum of 2 oz copper thickness is recommended. Additionally, a thermal interface material (TIM) with a thermal conductivity of 1 W/m-K or higher is suggested between the module and the heat sink.
• How do I ensure reliable start-up and shutdown of the power module?
  To ensure reliable start-up and shutdown, CUI recommends a soft-start circuit to limit inrush current and a shutdown circuit to prevent voltage spikes. Additionally, a minimum input capacitance of 10 uF is recommended to filter out noise and ensure stable operation.
• What is the maximum allowable ripple current on the input capacitors?
  CUI recommends limiting the input capacitor ripple current to 20% of the module's rated input current to ensure reliable operation and prevent overheating.
• Can I use this module in a high-vibration environment?
  Yes, the PDQ30-Q48-D15-D is designed to meet the vibration requirements of IEC 60068-2-6, but it's recommended to follow CUI's guidelines for vibration testing and to ensure proper PCB mounting and screw torque to prevent damage.
• How do I troubleshoot common issues like overvoltage, undervoltage, or overtemperature faults?
  CUI recommends using the module's built-in protection features and monitoring the fault pins to detect and troubleshoot issues. Additionally, checking the input voltage, output voltage, and temperature sensors can help identify the root cause of the fault.
