PDS2-S12-S5-M-TR - CUI Inc.

PDS2-S12-S5-M-TR Details

• Manufacturer Part Number:

  PDS2-S12-S5-M-TR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  PACKAGE-8/5 PIN

• ECCN Code:

  EAR99

• Manufacturer:

  CUI Inc

• YTEOL:

  0

• Analog IC - Other Type:

  DC-DC UNREGULATED POWER SUPPLY MODULE

• Efficiency (Main Output):

  79%

• Input Voltage-Max:

  13.2 V

• Input Voltage-Min:

  10.8 V

• Input Voltage-Nom:

  12 V

• JESD-30 Code:

  R-PDMA-G5

• Length:

  12.7 mm

• Line Regulation-Max:

  1.2%

• Load Regulation-Max:

  12%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  5

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.4 A

• Output Voltage-Nom:

  5 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,5/8LEAD,.44

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Packing Method:

  TR

• Protections:

  SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.03535 Vrms

• Seated Height-Max:

  7.5 mm

• Surface Mount:

  YES

• Technology:

  HYBRID

• Temperature Grade:

  OTHER

• Terminal Form:

  GULL WING

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Total Power Output-Max:

  2 W

• Trim/Adjustable Output:

  NO

• Width:

  8.3 mm
