PE42440MLBB-Z - Peregrine Semiconductor

Description: IC RF SWITCH SP4T 50 OHM 16QFN

Download PE42440MLBB-Z Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
PE42440MLBB-Z - Peregrine Semiconductor PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - 16-Lead 3 x 3 x 0.75mm QFN
click to zoom
3D Models
PE42440MLBB-Z - Peregrine Semiconductor  - 3D model - Quad Flat No-Lead - 16-Lead 3 x 3 x 0.75mm QFN
click to zoom

PE42440MLBB-Z Details

  • Manufacturer Part Number:

    PE42440MLBB-Z

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    3 X 3 MM, 0.75 MM HEIGHT, GREEN, QFN-16

  • Country Of Origin:

    Malaysia

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Manufacturer:

    pSemi

  • YTEOL:

    5.9

  • Additional Feature:

    CMOS COMPATIBLE, HIGH ISOLATION

  • Characteristic Impedance:

    50 Ω

  • Construction:

    COMPONENT

  • Input Power-Max (CW):

    32.99 dBm

  • Insertion Loss-Max:

    1.15 dB

  • JESD-609 Code:

    e3

  • Operating Frequency-Max:

    3000 MHz

  • Operating Frequency-Min:

    50 MHz

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • RF/Microwave Device Type:

    SP4T

  • Terminal Finish:

    MATTE TIN

  • VSWR-Max:

    1.17
