- Stock & Prices $ Price & Stock for PEC11L-4225F-S0015
- Part Number PEC11L-4225F-S0015
- Manufacturer Bourns
- Pin Count 7
- Part Category Undefined or Miscellaneous
- Package Category Other
- Footprint Name Other - PEC11L-4120F-S0020
- Released Date Jan 10, 2020
- Last Modified Date Aug 20, 2024 10:50 AM UTC
- Pinout / Pin List Click Here (Member Only)
PEC11L-4225F-S0015 Details
-
Manufacturer Part Number:
PEC11L-4225F-S0015
-
Rohs Code:
Yes
-
Part Life Cycle Code:
Active
-
Country Of Origin:
Mainland China
-
Factory Lead Time:
14 Weeks
-
Manufacturer:
Bourns Inc
-
Configuration:
SINGLE, 2 CHANNELS
-
JESD-609 Code:
e1
-
Mounting Feature:
CHASSIS MOUNT
-
Number of Functions:
1
-
Operating Temperature-Max:
80 °C
PEC11L-4225F-S0015 Frequently Asked Questions (FAQs)
-
Bourns recommends a symmetrical PCB layout with a solid ground plane, and keeping the input and output traces as short as possible to minimize parasitic inductance and capacitance.
-
Follow the recommended soldering profile and use a solder with a melting point below 260°C to prevent damage to the component. Ensure the PCB is clean and free of oxidation before soldering.
-
The PEC11L-4225F-S0015 is rated for operation from -40°C to +125°C, but derating may be necessary for high-temperature applications.
-
Yes, the PEC11L-4225F-S0015 is designed to withstand vibrations up to 10G, but it's essential to ensure the PCB is properly secured and the component is properly soldered to prevent mechanical stress.
-
Follow standard ESD handling procedures, such as using an ESD wrist strap, mat, or workstation, and ensure the PCB is properly grounded to prevent damage to the component.
Trust Checks
Expert Contribution
System Verified
Community Approved
PEC11L-4225F-S0015 Overview
Use the download button to access the PEC11L-4225F-S0015 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like PEC11,
