PESD5V0L7BAS - Nexperia

PESD5V0L7BAS Details

• Manufacturer Part Number:

  PESD5V0L7BAS

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  SOT-505-1, TSSOP-8

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Date Of Intro:

  2017-02-01

• Manufacturer:

  Nexperia

• YTEOL:

  0

• Additional Feature:

  LOW CAPACITANCE

• Breakdown Voltage-Max:

  7.9 V

• Breakdown Voltage-Min:

  7.2 V

• Configuration:

  COMMON ANODE, 8 ELEMENTS

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JESD-30 Code:

  S-PDSO-G8

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Non-rep Peak Rev Power Dis-Max:

  35 W

• Number of Elements:

  8

• Number of Terminals:

  8

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity:

  BIDIRECTIONAL

• Rep Pk Reverse Voltage-Max:

  5 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Finish:

  TIN

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30
