PESD5V0X2UAMBYL - Nexperia

PESD5V0X2UAMBYL Details

• Manufacturer Part Number:

  PESD5V0X2UAMBYL

• Brand Name:

  Nexperia

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  DFN

• Package Description:

  SOT883B, DFN1006B-3, 3 PIN

• Pin Count:

  3

• Manufacturer Package Code:

  SOT883B

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Factory Lead Time:

  8 Weeks

• Manufacturer:

  Nexperia

• YTEOL:

  7.01

• Additional Feature:

  IEC-61643-321; MIL-STD-883

• Breakdown Voltage-Max:

  10 V

• Breakdown Voltage-Min:

  7.5 V

• Breakdown Voltage-Nom:

  8.75 V

• Case Connection:

  ANODE

• Clamping Voltage-Max:

  14 V

• Configuration:

  COMMON ANODE, 2 ELEMENTS, 2 CHANNEL

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JESD-30 Code:

  R-PBCC-N3

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Non-rep Peak Rev Power Dis-Max:

  35 W

• Number of Elements:

  2

• Number of Terminals:

  3

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -65 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  CHIP CARRIER

• Peak Reflow Temperature (Cel):

  260

• Polarity:

  UNIDIRECTIONAL

• Reference Standard:

  AEC-Q101; IEC-60134; IEC-61000-4-2, 4-5

• Rep Pk Reverse Voltage-Max:

  5 V

• Reverse Current-Max:

  0.01 µA

• Reverse Test Voltage:

  5 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Finish:

  Tin (Sn)

• Terminal Form:

  NO LEAD

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  30
