PFC3514QM-231K06B-00 - TDK

PFC3514QM-231K06B-00 Details

• Manufacturer Part Number:

  PFC3514QM-231K06B-00

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Factory Lead Time:

  15 Weeks

• Manufacturer:

  TDK Corporation

• YTEOL:

  6

• Construction:

  Rectangular

• Core Material:

  FERRITE

• Inductance-Nom (L):

  230 µH

• Inductor Application:

  COMMON MODE CHOKE

• Inductor Type:

  COMMON MODE CHOKE

• Number of Functions:

  2

• Number of Terminals:

  8

• Operating Temperature-Max:

  120 °C

• Operating Temperature-Min:

  -30 °C

• Package Height:

  15.5 mm

• Package Length:

  37 mm

• Package Style:

  PCB Mount

• Package Width:

  30 mm

• Packing Method:

  Bulk

• Rated Current-Max:

  5.5 A

• Shape/Size Description:

  RECTANGULAR PACKAGE

• Shielded:

  NO

• Surface Mount:

  NO

• Terminal Placement:

  DUAL IN-LINE

• Terminal Shape:

  WIRE

• Test Frequency:

  65 MHz

• Tolerance:

  10%
