PH1200A280-28/T - TDK

PH1200A280-28/T Details

• Manufacturer Part Number:

  PH1200A280-28/T

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-16

• ECCN Code:

  EAR99

• Manufacturer:

  TDK Corporation

• YTEOL:

  9.8

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  IEC, UL, EN, CSA, CE

• Efficiency (Main Output):

  94%

• Input Voltage-Max:

  425 V

• Input Voltage-Min:

  200 V

• Input Voltage-Nom:

  280 V

• JESD-30 Code:

  R-XXMA-P16

• Length:

  116.8 mm

• Line Regulation-Max:

  0.01568%

• Load Regulation-Max:

  0.2%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  16

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  42.9 A

• Output Voltage-Max:

  33.6 V

• Output Voltage-Min:

  16.8 V

• Output Voltage-Nom:

  28 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  XMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Protections:

  OVER VOLTAGE; OVER CURRENT

• Screening Level:

  IEC 62368-1

• Seated Height-Max:

  13.2 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  UNSPECIFIED

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  1201.2 W

• Trim/Adjustable Output:

  YES

• Width:

  61 mm
