PHB4UEETS1A - LITTELFUSE

PHB4UEETS1A Details

• Manufacturer Part Number:

  PHB4UEETS1A

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  Littelfuse Inc

• Actuator Length:

  0.433 inch

• Actuator Material:

  POLYOXYMETHYLENE

• Actuator Travel:

  2.4892 mm

• Actuator Type:

  PUSHBUTTON

• Center Contact Material:

  PHOSPHOR BRONZE

• Center Contact Plating:

  SILVER

• Contact Current(DC)-Max:

  1 A

• Contact (DC) Max Rating R Load:

  1A@15VDC

• Contact Resistance:

  0.02 mΩ

• Contact Voltage(DC)-Max:

  15 V

• Dielectric Withstand Volts:

  500VDC V

• Electrical Life:

  10000 Cycle(s)

• End Contact Material:

  BRASS

• End Contact Plating:

  SILVER

• Housing Material:

  POLYAMIDE

• Illumination:

  NON-ILLUMINATED

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  PHENOLIC

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operating Temperature-Max:

  60 °C

• Operating Temperature-Min:

  -10 °C

• PCB Hole Count:

  6

• Sealing:

  EPOXY

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Type:

  PUSHBUTTON SWITCH

• Terminal Length:

  0.138 inch

• Termination Type:

  SOLDER
