PHDMI2F4X - Nexperia

PHDMI2F4X Details

• Manufacturer Part Number:

  PHDMI2F4X

• Brand Name:

  Nexperia

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Not Recommended

• Part Package Code:

  DFN

• Package Description:

  DFN2510A-10, SOT-1176-1, 10 PIN

• Pin Count:

  10

• Manufacturer Package Code:

  SOT1176-1

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Nexperia

• YTEOL:

  3

• Breakdown Voltage-Min:

  6 V

• Clamping Voltage-Max:

  4.6 V

• Configuration:

  SINGLE, 4 CHANNEL

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JESD-30 Code:

  R-PDSO-N10

• JESD-609 Code:

  e4

• Moisture Sensitivity Level:

  1

• Number of Elements:

  1

• Number of Terminals:

  10

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity:

  UNIDIRECTIONAL

• Reference Standard:

  IEC-60134; IEC-61000-4-2, 4-5

• Rep Pk Reverse Voltage-Max:

  3 V

• Reverse Current-Max:

  1 µA

• Reverse Test Voltage:

  3 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Finish:

  NICKEL PALLADIUM GOLD SILVER

• Terminal Form:

  NO LEAD

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30
