PHPT61003NYX - Nexperia

PHPT61003NYX Details

• Manufacturer Part Number:

  PHPT61003NYX

• Brand Name:

  Nexperia

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  SOIC

• Package Description:

  SOT-669, SOP-8, 4 PIN

• Pin Count:

  4

• Manufacturer Package Code:

  SOT669

• Country Of Origin:

  Philippines

• ECCN Code:

  EAR99

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Nexperia

• YTEOL:

  4

• Case Connection:

  COLLECTOR

• Collector Current-Max (IC):

  3 A

• Collector-Base Capacitance-Max:

  11 pF

• Collector-Emitter Voltage-Max:

  100 V

• Configuration:

  SINGLE

• DC Current Gain-Min (hFE):

  10

• JEDEC-95 Code:

  MO-235

• JESD-30 Code:

  R-PSSO-G4

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Number of Elements:

  1

• Number of Terminals:

  4

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  NPN

• Power Dissipation-Max (Abs):

  25 W

• Reference Standard:

  IEC-60134

• Surface Mount:

  YES

• Terminal Finish:

  Tin (Sn)

• Terminal Form:

  GULL WING

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  30

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON

• Transition Frequency-Nom (fT):

  140 MHz

• VCEsat-Max:

  0.33 V
