Diodes Incorporated provides a recommended PCB layout guide in the application note ANP-COM-001, which includes guidelines for signal routing, power plane layout, and decoupling capacitor placement.
To ensure signal integrity, use controlled impedance traces, minimize trace lengths, and use termination resistors as close to the signal source as possible. Additionally, use a signal integrity analysis tool to simulate and optimize the signal integrity.
The PI5A23157UEX is rated for operation from -40°C to 125°C (junction temperature). However, the device's performance may degrade at higher temperatures, and it's recommended to derate the device's specifications accordingly.
Yes, the PI5A23157UEX is a PCIe-compliant device, and it can be used in PCIe applications. However, ensure that the device is configured correctly for the specific application, and follow the PCIe specification guidelines for signal routing and termination.
Diodes Incorporated recommends using a decoupling capacitor scheme with a combination of high-frequency and low-frequency capacitors (e.g., 0.1uF and 10uF capacitors) to ensure stable power supply voltage to the device.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
PI5A23157UEX Overview
Use the download button to access the PI5A23157UEX schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like PI5A2,
or try a keyword search, such as Multiplexers or Switches
