PI6C49CB01JWEX - Diodes Incorporated

Description: Clock Buffer Clock Buffer SO-8 T&R 2.5K, Clock Translator IC 1:1 360 MHz 8-SOIC (0.154", 3.90mm Width)

Download PI6C49CB01JWEX Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
PI6C49CB01JWEX - Diodes Incorporated PCB footprint - Small Outline Packages - Small Outline Packages - 8-SOIC (W)_2026
click to zoom
3D Models
PI6C49CB01JWEX - Diodes Incorporated  - 3D model - Small Outline Packages - 8-SOIC (W)_2026
click to zoom

PI6C49CB01JWEX Details

  • Manufacturer Part Number:

    PI6C49CB01JWEX

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    SOIC-8

  • Country Of Origin:

    Taiwan

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    12 Weeks

  • Manufacturer:

    Diodes Incorporated

  • YTEOL:

    7

  • Delay-Max:

    2 ns

  • Interface IC Type:

    LVCMOS/LVTTL TO LVHSTL TRANSLATOR

  • JESD-30 Code:

    R-PDSO-G8

  • Length:

    4.9 mm

  • Number of Functions:

    1

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    105 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Equivalence Code:

    SOP8,.25

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Seated Height-Max:

    1.75 mm

  • Supply Current-Max:

    35 mA

  • Supply Voltage-Max:

    3.465 V

  • Supply Voltage-Min:

    2.375 V

  • Supply Voltage-Nom:

    2.5 V

  • Surface Mount:

    YES

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Width:

    3.9 mm

PI6C49CB01JWEX Frequently Asked Questions (FAQs)

  • The recommended operating voltage range for PI6C49CB01JWEX is 1.71V to 1.89V, with a typical voltage of 1.8V.
  • To ensure signal integrity, use a low-impedance PCB design, keep signal traces short, and use termination resistors as needed. Also, follow the recommended layout guidelines in the datasheet.
  • The maximum clock frequency supported by PI6C49CB01JWEX is 100 MHz.
  • No, PI6C49CB01JWEX is not recommended for use in 3.3V systems. It is designed for 1.8V operation and may not function correctly or may be damaged if operated at 3.3V.
  • Follow the recommended thermal management guidelines in the datasheet, including using a heat sink or thermal pad, and ensuring good airflow around the device.

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

PI6C49CB01JWEX Overview

Use the download button to access the PI6C49CB01JWEX schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like PI6C4, or try a keyword search, such as Level Translators
