PIC16F15386-E/PT - Microchip

Description: 8-bit Microcontrollers - MCU 28KB, 2KB RAM, 4xPWMs, Comparator, DAC, ADC, CWG, 4xCLC, 2 EUSART, SPI/I2C

Download ECAD Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download

PCB Footprints

PIC16F15386-E/PT - Microchip PCB footprint - Quad Flat Packages - Quad Flat Packages - 48-Lead Thin Quad Flatpack (PT) - 7x7x1.0 mm Body [TQFP]
click to zoom

3D Models

PIC16F15386-E/PT - Microchip  - 3D model - Quad Flat Packages - 48-Lead Thin Quad Flatpack (PT) - 7x7x1.0 mm Body [TQFP]
click to zoom
  • Datasheet Download Datasheet
  • Stock & Prices $ Check Stock & Prices
  • Part Number PIC16F15386-E/PT
  • Manufacturer Microchip
  • Pin Count 48
  • Part Category Integrated Circuit
  • Package Category Quad Flat Packages
  • Footprint Name Quad Flat Packages - 48-Lead Thin Quad Flatpack (PT) - 7x7x1.0 mm Body [TQFP]
  • Released Date Sep 25, 2017
  • Pinout / Pin List Click Here (Member Only)
