PJB1-RFKW-09 - MORETHANALL

PJB1-RFKW-09 Details

• Manufacturer Part Number:

  PJB1-RFKW-09

• Part Life Cycle Code:

  Contact Manufacturer

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Morethanall Co Ltd

• Additional Feature:

  ROHS COMPLIANT

• Audio Type:

  PHONO

• Board Mounting Option:

  SOLDERABLE RETENTION CLIPS

• Body Breadth:

  0.969 inch

• Body Depth:

  0.789 inch

• Body Length:

  0.52 inch

• Body/Shell Style:

  JACK

• Connector Type:

  3.5MM AUDIO

• Contact Finish Mating:

  AU

• Contact Finish Termination:

  TIN

• Contact Gender:

  FEMALE

• Contact Material:

  BRASS

• Contact Resistance:

  50 mΩ

• Contact Style:

  RND PIN-SKT

• Dielectric Withstanding Voltage:

  500VAC V

• Durability:

  1500 Cycles

• Insertion Force-Max:

  29.8016 N

• Insulation Resistance:

  100000000 Ω

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number of Poles:

  2

• Number of Ports:

  2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• Rated Current (Signal):

  1 A

• Shell Material:

  BRASS

• Terminal Length:

  0.106 inch

• Termination Type:

  SOLDER

• Withdrawl Force-Min:

  3.9198 N
