PJRAN1X1U01X - Switchcraft

PJRAN1X1U01X Details

• Manufacturer Part Number:

  PJRAN1X1U01X

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Switchcraft Conxall

• YTEOL:

  8

• Additional Feature:

  STANDARD: UL 94HB

• Audio Type:

  PHONO

• Body Breadth:

  0.512 inch

• Body Depth:

  0.768 inch

• Body Diameter:

  0.327 inch

• Body Length:

  0.394 inch

• Body/Shell Style:

  JACK

• Configuration:

  1X1 HORIZONTAL

• Connector Type:

  RCA

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Finish Termination:

  NICKEL

• Contact Gender:

  FEMALE

• Contact Resistance:

  30 mΩ

• Contact Style:

  RND PIN-SKT

• DIN Conformance:

  NO

• Dielectric Withstanding Voltage:

  500V V

• IEC Conformance:

  NO

• Insertion Force-Max:

  1.023 N

• Insulator Color:

  BLACK

• Insulator Material:

  ACRYLONITRILE BUTADIENE STYRENE

• MIL Conformance:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD AND PANEL

• Number of Poles:

  1

• Number of Ports:

  1

• Operating Temperature-Max:

  80 °C

• Operating Temperature-Min:

  -25 °C

• Option:

  GENERAL PURPOSE

• Rated Current (Signal):

  2 A

• Reference Standard:

  UL

• Shell Finish:

  NICKEL

• Shell Material:

  COPPER ALLOY

• Terminal Length:

  0.158 inch

• Termination Type:

  SOLDER
