PJS008-2000-0 - Yamaichi

PJS008-2000-0 Details

• Manufacturer Part Number:

  PJS008-2000-0

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Manufacturer:

  Yamaichi Electronics Co Ltd

• YTEOL:

  0

• Additional Feature:

  ROHS COMPLIANT & 1000PCS/REEL

• Board Mounting Option:

  FITTING NAIL

• Body Breadth:

  0.073 inch

• Body Depth:

  0.583 inch

• Body Length:

  0.618 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  PCB CONNECTOR

• Contact Finish Mating:

  AU ON NI

• Contact Gender:

  FEMALE

• Contact Pattern:

  RECTANGULAR

• Contact Resistance:

  100 mΩ

• Contact Style:

  COMPRESSION

• Dielectric Withstanding Voltage:

  700VAC V

• Durability:

  10000 Cycles

• Filter Feature:

  NO

• Insulation Resistance:

  1000000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  LIQUID CRYSTAL POLYMER

• Mating Contact Pitch:

  0.043 inch

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number Of PCB Rows:

  1

• Number of Ports:

  1

• Number of Rows Loaded:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  RECTANGULAR

• Rated Current (Signal):

  0.5 A

• Reference Standard:

  UL

• Terminal Pitch:

  1.0922 mm

• Termination Type:

  SURFACE MOUNT

• Total Number of Contacts:

  8

• UL Flammability Code:

  94V-0
