PKB4216CPIHS - Flex Power Modules

PKB4216CPIHS Details

• Manufacturer Part Number:

  PKB4216CPIHS

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  1/8 BRICK PACKAGE-8

• ECCN Code:

  EAR99

• Factory Lead Time:

  18 Weeks

• Manufacturer:

  Flex Ltd

• YTEOL:

  7.3

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  IEC, EN, UL

• Efficiency (Main Output):

  95.1%

• Input Voltage-Max:

  75 V

• Input Voltage-Min:

  36 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  R-XDMA-P8

• Length:

  58.1 mm

• Line Regulation-Max:

  0.003%

• Load Regulation-Max:

  0.05%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -30 °C

• Output Current-Max:

  6.67 A

• Output Voltage-Max:

  33 V

• Output Voltage-Min:

  15 V

• Output Voltage-Nom:

  30 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  INPUT UNDER VOLTAGE, OUTPUT OVER VOLTAGE, SHORT CICUIT, THERMAL

• Ripple Voltage (Main Out):

  0.031815 Vrms

• Screening Level:

  IEC 62368-1

• Seated Height-Max:

  13.7 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  200 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.011 s

• Width:

  22.7 mm
