PLA133-97QAVAO - Microchip

PLA133-97QAVAO Details

• Manufacturer Part Number:

  PLA133-97QAVAO

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  VQFN-16

• Pin Count:

  16

• Manufacturer Package Code:

  VQFN-16

• Country Of Origin:

  Thailand

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  6 Weeks

• Date Of Intro:

  2020-05-14

• Manufacturer:

  Microchip Technology Inc

• YTEOL:

  19

• Family:

  PLA133

• Input Conditioning:

  STANDARD

• JESD-30 Code:

  S-PQCC-N16

• Length:

  3 mm

• Logic IC Type:

  LOW SKEW CLOCK DRIVER

• Max I(ol):

  0.008 A

• Number of Functions:

  1

• Number of Terminals:

  16

• Number of True Outputs:

  9

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC16,.12SQ,20

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Packing Method:

  TUBE

• Power Supply Current-Max (ICC):

  32 mA

• Propagation Delay (tpd):

  9.2 ns

• Same Edge Skew-Max (tskwd):

  0.25 ns

• Screening Level:

  AEC-Q100

• Seated Height-Max:

  1 mm

• Supply Voltage-Max (Vsup):

  3.63 V

• Supply Voltage-Min (Vsup):

  1.71 V

• Supply Voltage-Nom (Vsup):

  1.8 V

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  3 mm
