PMDT290UNEH - Nexperia

PMDT290UNEH Details

• Manufacturer Part Number:

  PMDT290UNEH

• Brand Name:

  Nexperia

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  SOT

• Package Description:

  SOT-666, 6 PIN

• Pin Count:

  6

• Manufacturer Package Code:

  SOT666

• ECCN Code:

  EAR99

• Factory Lead Time:

  8 Weeks

• Manufacturer:

  Nexperia

• YTEOL:

  5.15

• Configuration:

  SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  20 V

• Drain Current-Max (ID):

  0.8 A

• Drain-source On Resistance-Max:

  0.38 Ω

• FET Technology:

  TRENCH MOSFET

• Feedback Cap-Max (Crss):

  7 pF

• JESD-30 Code:

  R-PDSO-F6

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Number of Elements:

  2

• Number of Terminals:

  6

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  0.5 W

• Pulsed Drain Current-Max (IDM):

  3.2 A

• Reference Standard:

  IEC-60134

• Surface Mount:

  YES

• Terminal Finish:

  Tin (Sn)

• Terminal Form:

  FLAT

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
