POS-100+ - Mini-Circuits

POS-100+ Details

• Manufacturer Part Number:

  POS-100+

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• Manufacturer:

  Mini-Circuits

• YTEOL:

  0

• Control Voltage-Max:

  16 V

• Control Voltage-Min:

  1 V

• JESD-609 Code:

  e2

• Modulation Sensitivity:

  4.8 MHz/V

• Mounting Feature:

  THROUGH HOLE MOUNT

• Number of Terminals:

  8

• Offset Frequency:

  1 kHz

• Operating Frequency-Max:

  100 MHz

• Operating Frequency-Min:

  50 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Oscillator Type:

  VOLTAGE CONTROLLED OSCILLATOR

• Output Power:

  8.3 dBm

• Package Body Material:

  METAL

• Package Equivalence Code:

  DIP8,.2,200

• Phase Noise:

  -83 dBc/Hz

• Physical Dimension:

  20.32mm x 10.16mm x 7.874mm

• Qualification Status:

  Not Qualified

• Supply Current-Max:

  20 mA

• Supply Voltage-Nom:

  12 V

• Surface Mount:

  NO

• Terminal Finish:

  Tin/Silver (Sn/Ag)
