PPC405GPR-3KB400 - Applied Micro Circuits

PPC405GPR-3KB400 Details

• Manufacturer Part Number:

  PPC405GPR-3KB400

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  BGA

• Package Description:

  BGA, BGA456,26X26,40

• Pin Count:

  456

• Reach Compliance Code:

  Compliant

• ECCN Code:

  3A991.a.2

• HTS Code:

  8542.31.00.25

• Manufacturer:

  Applied Micro Circuits Corporation

• YTEOL:

  0

• Additional Feature:

  ALSO REQUIRES 3.3V SUPPLY

• Address Bus Width:

  32

• Bit Size:

  32

• Boundary Scan:

  YES

• Clock Frequency-Max:

  66.66 MHz

• External Data Bus Width:

  32

• Format:

  FIXED POINT

• Integrated Cache:

  YES

• JESD-30 Code:

  S-PBGA-B456

• Length:

  27 mm

• Low Power Mode:

  YES

• Number of Terminals:

  456

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  BGA

• Package Equivalence Code:

  BGA456,26X26,40

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  2.65 mm

• Speed:

  400 MHz

• Supply Voltage-Max:

  1.9 V

• Supply Voltage-Min:

  1.8 V

• Supply Voltage-Nom:

  1.85 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  BALL

• Terminal Pitch:

  1 mm

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Width:

  27 mm

• uPs/uCs/Peripheral ICs Type:

  MICROPROCESSOR, RISC
