PQ60050QTA30NRS-G - Synqor

PQ60050QTA30NRS-G Details

• Manufacturer Part Number:

  PQ60050QTA30NRS-G

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Contact Manufacturer

• Part Package Code:

  MODULE

• Package Description:

  1/4 BRICK PACKAGE-8

• Pin Count:

  8

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• Manufacturer:

  SynQor

• YTEOL:

  2

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CAN, CSA, CUL, EN, IEC, UL, TUV

• Efficiency (Main Output):

  91%

• Input Voltage-Max:

  75 V

• Input Voltage-Min:

  35 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  R-XDMA-P8

• Length:

  58.4 mm

• Line Regulation-Max:

  0.2%

• Load Regulation-Max:

  0.2%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  30 A

• Output Voltage-Max:

  5.5 V

• Output Voltage-Min:

  4 V

• Output Voltage-Nom:

  5 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,8LEAD,2

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER CURRENT, OVER VOLTAGE, OVER TEMPERATURE, SHORT CIRCUIT, UNDER VOL

• Qualification Status:

  Not Qualified

• Ripple Voltage (Main Out):

  0.02 Vrms

• Seated Height-Max:

  11.4 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Finish:

  Matte Tin (Sn) - with Nickel (Ni) barrier

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  150 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.0092 s

• Width:

  36.8 mm
