PQ60120HPA20NRS-G - Synqor

PQ60120HPA20NRS-G Details

• Manufacturer Part Number:

  PQ60120HPA20NRS-G

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  1/2 BRICK PACKAGE-9/8

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• Manufacturer:

  SynQor

• YTEOL:

  7

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CUL, EN, IEC, TUV, UL

• Efficiency (Main Output):

  93.5%

• Input Voltage-Max:

  75 V

• Input Voltage-Min:

  35 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  R-XDMA-P8

• Length:

  61 mm

• Line Regulation-Max:

  0.1%

• Load Regulation-Max:

  0.2%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  20 A

• Output Voltage-Max:

  13.2 V

• Output Voltage-Min:

  9.6 V

• Output Voltage-Nom:

  12 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,8/9LEAD(UNSPEC)

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  260

• Protections:

  OVER CURRENT, OVER VOLTAGE, OVER TEMPERATURE, SHORT CIRCUIT, UNDER VOL

• Ripple Voltage (Main Out):

  0.03 Vrms

• Seated Height-Max:

  10.8 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  10

• Total Power Output-Max:

  240 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.024 s

• Width:

  58.4 mm
