PQ60120HPA20NRS - Synqor

PQ60120HPA20NRS Details

• Manufacturer Part Number:

  PQ60120HPA20NRS

• Pbfree Code:

  No

• Part Life Cycle Code:

  Active

• Part Package Code:

  MODULE

• Pin Count:

  11/10

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• Manufacturer:

  SynQor

• YTEOL:

  5

• Additional Feature:

  REMOTE SHUTDOWN

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  UL, TUV

• Efficiency (Main Output):

  92.5%

• Input Voltage-Max:

  75 V

• Input Voltage-Min:

  35 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  R-XDMA-P10

• JESD-609 Code:

  e0

• Length:

  61 mm

• Line Regulation-Max:

  0.1%

• Load Regulation-Max:

  0.2%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  10

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  20 A

• Output Voltage-Max:

  13.2 V

• Output Voltage-Min:

  9.6 V

• Output Voltage-Nom:

  12 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Qualification Status:

  Not Qualified

• Ripple Voltage (Main Out):

  0.03535 Vrms

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Finish:

  TIN LEAD OVER NICKEL

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  240 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.024 s

• Width:

  58.4 mm
