PRM48BT480M500A00 - VICOR

PRM48BT480M500A00 Details

• Manufacturer Part Number:

  PRM48BT480M500A00

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  Module-32

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Vicor Corporation

• YTEOL:

  0

• Analog IC - Other Type:

  SWITCHING REGULATOR

• Input Voltage-Max:

  55 V

• Input Voltage-Min:

  38 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  R-XQMA-T32

• JESD-609 Code:

  e4

• Length:

  32.5 mm

• Moisture Sensitivity Level:

  6

• Number of Functions:

  1

• Number of Terminals:

  32

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  10.42 A

• Output Voltage-Max:

  55 V

• Output Voltage-Min:

  20 V

• Output Voltage-Nom:

  48 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  QMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Seated Height-Max:

  6.98 mm

• Supply Voltage-Nom (Vsup):

  48 V

• Surface Mount:

  NO

• Switcher Configuration:

  BUCK-BOOST

• Switching Frequency-Max:

  1070 kHz

• Technology:

  HYBRID

• Temperature Grade:

  MILITARY

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  QUAD

• Width:

  22 mm
