PRQ3W-Q48-D55-S - CUI Inc.

PRQ3W-Q48-D55-S Details

• Manufacturer Part Number:

  PRQ3W-Q48-D55-S

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  PACKAGE-10/7

• ECCN Code:

  EAR99

• Date Of Intro:

  2020-06-03

• Manufacturer:

  CUI Inc

• YTEOL:

  7.5

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE, EN, IEC

• Efficiency (Main Output):

  78%

• Input Voltage-Max:

  80 V

• Input Voltage-Min:

  18 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  R-PSMA-T7

• Length:

  27.4 mm

• Line Regulation-Max:

  0.5%

• Load Regulation-Max:

  1%

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  7

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.3 A

• Output Voltage-Max:

  5.15 V

• Output Voltage-Min:

  4.85 V

• Output Voltage-Nom:

  5 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Protections:

  OUTPUT OVER CURRENT; UNDER VOLTAGE; SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.053025 Vrms

• Seated Height-Max:

  12.5 mm

• Surface Mount:

  NO

• Switching Frequency-Max:

  300 kHz

• Technology:

  HYBRID

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  3 W

• Trim/Adjustable Output:

  NO

• Warm-up Time:

  0.01 s

• Width:

  9.5 mm
