PRTR5V0U2F,115 - Nexperia

PRTR5V0U2F,115 Details

• Manufacturer Part Number:

  PRTR5V0U2F,115

• Brand Name:

  Nexperia

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  SON

• Package Description:

  SOT-886, XSON-6

• Pin Count:

  6

• Manufacturer Package Code:

  SOT886

• Country Of Origin:

  Mainland China, Malaysia

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Factory Lead Time:

  8 Weeks

• Date Of Intro:

  2017-02-01

• Manufacturer:

  Nexperia

• YTEOL:

  6.21

• Breakdown Voltage-Max:

  9 V

• Breakdown Voltage-Min:

  6 V

• Breakdown Voltage-Nom:

  7.5 V

• Configuration:

  SINGLE, 2 CHANNEL

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JEDEC-95 Code:

  MO-252

• JESD-30 Code:

  R-PBCC-N6

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Number of Elements:

  1

• Number of Terminals:

  6

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  CHIP CARRIER

• Peak Reflow Temperature (Cel):

  260

• Polarity:

  UNIDIRECTIONAL

• Reference Standard:

  AEC-Q101; IEC-60134; IEC-61000-4-2; MIL-STD-883

• Rep Pk Reverse Voltage-Max:

  5.5 V

• Reverse Current-Max:

  0.01 µA

• Reverse Test Voltage:

  5.5 V

• Surface Mount:

  YES

• Technology:

  ZENER

• Terminal Finish:

  TIN

• Terminal Form:

  NO LEAD

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  30
