PS1608GT2-R50-T1 Details

  • Manufacturer Part Number:

    PS1608GT2-R50-T1

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Japan

  • Manufacturer:

    Susumu Co Ltd

  • YTEOL:

    7

  • Characteristic Impedance:

    50 Ω

  • Construction:

    COMPONENT

  • Input Power-Max (CW):

    20 dBm

  • Insertion Loss-Max:

    6 dB

  • JESD-609 Code:

    e3

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    3

  • Operating Frequency-Max:

    20000 MHz

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • RF/Microwave Device Type:

    SPLITTER

  • Surface Mount:

    YES

  • Terminal Finish:

    MATTE TIN

  • VSWR-Max:

    1.5
