PS2012GT2-R50-T1 - Susumu

Description: Signal Conditioning RF POWER DIVIDER 0HZ-17.5GHZ 0805

Download PS2012GT2-R50-T1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
PS2012GT2-R50-T1 - Susumu PCB footprint - Other - Other - PS2012GT2-R50-T1-1
click to zoom
3D Models
PS2012GT2-R50-T1 - Susumu  - 3D model - Other - PS2012GT2-R50-T1-1
click to zoom

PS2012GT2-R50-T1 Details

  • Manufacturer Part Number:

    PS2012GT2-R50-T1

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Manufacturer:

    Susumu Co Ltd

  • YTEOL:

    7

  • Characteristic Impedance:

    50 Ω

  • Construction:

    COMPONENT

  • Input Power-Max (CW):

    20.97 dBm

  • Insertion Loss-Max:

    6 dB

  • JESD-609 Code:

    e3

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    3

  • Operating Frequency-Max:

    17500 MHz

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • RF/Microwave Device Type:

    SPLITTER

  • Surface Mount:

    YES

  • Terminal Finish:

    MATTE TIN

  • VSWR-Max:

    1.5
