PT15NH05-503A2020-S - Amphenol

PT15NH05-503A2020-S Details

• Manufacturer Part Number:

  PT15NH05-503A2020-S

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8533.40.80.70

• Factory Lead Time:

  4 Days

• Manufacturer:

  Amphenol Corporation

• YTEOL:

  6.5

• Actuator Orientation:

  HORIZONTAL

• Actuator Type:

  SHAFT; THUMB WHEEL

• Construction:

  Rectangular

• Ganging Number:

  1

• Lead Length:

  4 mm

• Mounting Feature:

  PCB MOUNT

• Number of Terminals:

  3

• Number of Turns:

  1

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -25 °C

• Package Height:

  17.5 mm

• Package Length:

  15 mm

• Package Style:

  PCB Mount

• Package Width:

  6 mm

• Packing Method:

  BULK

• Rated Power Dissipation (P):

  0.25 W

• Rated Temperature:

  50 °C

• Resistance:

  50000 Ω

• Resistance Law:

  LINEAR

• Resistor Type:

  POTENTIOMETER

• Rotational Angle:

  240 deg

• Surface Mount:

  NO

• Technology:

  CARBON

• Temperature Coefficient:

  300 ppm/°C

• Terminal Shape:

  FLAT

• Tolerance:

  20%

• Working Voltage:

  250 V
