PT2260-R4S - Princeton Technology Corp

PT2260-R4S Details

• Manufacturer Part Number:

  PT2260-R4S

• Part Life Cycle Code:

  Contact Manufacturer

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Princeton Technology Corporation

• Consumer IC Type:

  REMOTE CONTROL TRANSMITTER IC

• JESD-30 Code:

  R-PDSO-G16

• Length:

  9.9 mm

• Number of Functions:

  1

• Number of Terminals:

  16

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SOP

• Package Equivalence Code:

  SOP16,.25

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  1.75 mm

• Supply Voltage-Max (Vsup):

  10 V

• Supply Voltage-Min (Vsup):

  1.8 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Transmission Media:

  RF

• Width:

  3.9 mm
