PT271024 - TE Connectivity

PT271024 Details

• Manufacturer Part Number:

  PT271024

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Factory Lead Time:

  27 Weeks, 5 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  6.59

• Additional Feature:

  RELEASE TIME WITH DIODE

• Body Height:

  30 mm

• Body Length or Diameter:

  28 mm

• Coil Current(DC)-Max:

  0.031 A

• Coil Operate Voltage(DC):

  18 V

• Coil Power:

  741 mW

• Coil Release Voltage(DC):

  2.4 V

• Coil Resistance:

  777 Ω

• Coil Voltage(DC)-Max:

  24 V

• Coil Voltage-Nom:

  24 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Power Rating R Load:

  3000VA@400VAC

• Contact (AC) Max Rating R Load:

  12A@400VAC

• Contact Current(AC)-Max:

  12 A

• Contact Current(DC)-Max:

  12 A

• Contact Voltage(AC)-Max:

  400 V

• Contact/Output Supply Type:

  AC

• Electrical Life:

  100000 Cycle(s)

• End Contact Material:

  SILVER NICKEL

• Input Switching Control Type:

  Random

• Mounting Feature:

  PANEL MOUNT

• Number of Terminals:

  8

• Operate Time:

  23 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX; TUBE

• Physical Dimension:

  28MM X 22.5MM X 30MM

• Reference Standard:

  UL; VDE

• Relay Action:

  MOMENTARY

• Relay Form:

  2 FORM C

• Relay Function:

  DPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  15 ms

• Sealing:

  RT2

• Surface Mount:

  NO

• Terminal Length:

  0.004099568199136398 inch

• Termination Type:

  SOLDER/QUICK CONNECT
