PTVS20-015C-H - Bourns

PTVS20-015C-H Details

• Manufacturer Part Number:

  PTVS20-015C-H

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DFN, 2 PIN

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Factory Lead Time:

  24 Weeks

• Manufacturer:

  Bourns Inc

• YTEOL:

  7

• Breakdown Voltage-Max:

  19 V

• Breakdown Voltage-Min:

  16 V

• Breakdown Voltage-Nom:

  17.5 V

• Case Connection:

  ANODE

• Clamping Voltage-Max:

  26 V

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JESD-30 Code:

  R-PBCC-N2

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  CHIP CARRIER

• Polarity:

  BIDIRECTIONAL

• Reference Standard:

  IEC-61000-4-5; MIL-STD-750

• Rep Pk Reverse Voltage-Max:

  15 V

• Reverse Current-Max:

  10 µA

• Reverse Test Voltage:

  15 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Finish:

  Tin (Sn)

• Terminal Form:

  NO LEAD

• Terminal Position:

  BOTTOM
